Slip Ring Induction Motor

The slip ring induction motor has two distinctly separate parts, one is the stator and other is the rotor. The stator circuit is rated as same in the squirrel cage motor, but the rotor is rated in frame voltage or short circuit current.

A slip ring (in electrical engineering terms) is a method of making an electrical connection through a rotating assembly. Slip rings, also called rotary electrical interfaces, rotating electrical connectors, collectors, swivels or electrical rotary joints, are commonly found in electrical generators for AC systems and alternators and in packaging machinery, cable reels, and wind turbines.

A slip ring consists of a conductive circle or band mounted on a shaft and insulated from it. Electrical connections from the rotating part of the system, such as the rotor of a generator, are made to the ring. Fixed contacts or brushes run in contact with the ring, transferring electrical power or signals to the exterior, static part of the system.
